Rubber Moulding Hydraulic Press is used to amplify production, save manpower, rejection time & space, improve quality and electric power. The range of moulding press is perfect for product consistency as it gives excellent surface finish, low & high automation capabilities and dimensional stability. These moulding presses can be operated manually as well as automatically. Known for high performance, quality, durability and efficiency, these presses are highly demanded for Rubber moulding products.

Hydropower offers Compression Moulding Hydraulic Presses in Single station and in Multi-Station systems operating with one common power pack. All these moulding presses are provided with individual zone controllers and are offered along with temperature controlled heated platens for independently heated tools.

We design moulding presses according to customer requirements. One of the typical customized hot press is mentioned below:

Features :

• High productivity at Lower operating cost

• Multi Station Presses operating with One common power pack.

• User Friendly operation.

• Seals of Reliable brands used.

• Reliable operation and Low maintenance.

• High Grade Quality Plates used.

• Alloy Chilled Rams duly grinded

• Steam or Electric or Thermal Oil Heating system.

• Auto Bumping System to release unwanted air trapped during curing process.

• High Quality and Reputed Brand make Electric and Hydraulic components.

• Sequence of Auto Operation controlled through Standard Panel and PLC also available optionally.

• Equipped with Alarm and Safety Systems

1. Capacity: 1200 Ton.

2. Working pressure: 250 Bar.

3. Table size: 1650X1650mm .

4. Daylight: 600mm.

5. Type of press: 4 Pillar, Up stroking.

6. Working Temperature: 140-180°c.

7. Timer Capacity: 60 MINUTES.

8. Ram stroke: 500mm.

9. Platen Return: Pull back cylinder.

10. Mode of operation: By push button/ PLC.

11. Oil tank capacity: 1200 Liters.

12. Low pressure pump: 260 LPM OUTPUT AT 30 BAR.

13. High pressure pump: 10 LPM AT 250 BAR.

14. Electric Motor: 25 H.P, 1450 Rpm, 3Phase..

• Auto Parts Moulding.

• Oil Seal Moulding.

• Hot Water Bag Moulding.

• O Ring Moulding.

• Rubber Bushes Moulding.

• Engine Rubber Mountings Moulding.

• Rubber Sheets, Washers, Springs and many rubber parts Moulding.
